shop drawings for a steel bicycle storage box

700
ETH, DAI, USDT
+55
0 days (till Jul 11th, 2025)

1 Project goal

Prepare a PDF package (shop drawings + assembly manual) for an improved version of my prototype bicycle box with a folding, upward-opening lid.

2 Input from me

Photos and a dimensioned sketch



3 Key requirements

AreaRequirements
StructureSteel frames made of closed profiles (preferred 40 × 40 × 2 mm S235 galvanised, but other sizes acceptable – I can buy additional stock). Walls, roof and lid clad with T7 trapezoidal sheet, 0.5 mm (specification – Blachotrapez).
JointsWeld wherever practical; use bolts where welding is impossible/ill-advised. Each wall (left, right, rear) and the roof to be separate frames bolted together on site.
Lid mechanism• Propose hinges and folding geometry. • Select and position a gas strut so opening/closing is light; lid must stay open unaided.
LockingRobust lock, 1–2 locking points – please recommend a proven solution.
AnchoringBox will stand on a concrete slab / paving. Provide base holes and specify chemical anchors.
Packing / transportSplit the design so main parts are ≤ 2.5 m long (roof preferably in one piece). Avoid unnecessary small items – keep parcel count reasonable.
Corrosion protectionAfter welding I will do local zinc-spray touch-ups; reflect this in details.
Documentation1) Assembly and exploded views 2) Part drawings with dimensions & holes 3) Bill of materials + fastener list 4) Step-by-step “IKEA-style” assembly manual (line graphics). All files in PDF (DWG/STEP welcome but optional).



4 Your tasks

Analyse my sketch and prototype.

Optimise the design for strength and function (lid, hinges, gas strut).

Produce the full set of shop drawings and the assembly manual.




Project Brief – Bicycle Storage Box

Goal: Full set of shop drawings + IKEA-style assembly manual so I can fabricate an upgraded version of my prototype box at home.

Box size: ~2430 × 1265 × 1515 mm (see sketch). Minor deviations allowed.

Structure

Steel frames, preferred 40 × 40 × 2 mm S235 galvanised RHS (can be changed if justified).

Cladding: T7 trapezoidal sheet, 0.5 mm, Blachotrapez.

Each wall (left, right, rear) and roof as separate welded frames, bolted together on site.

Lid

Folding, upward-opening panel.

Engineer hinges + gas strut so the lid lifts easily and stays open.

Robust handle and lock (1- or 2-point).

Anchoring: Pre-drilled base plates for chemical anchors into concrete/pavers.

Packaging: Break the build into parts ≤ 2.5 m long; keep parcel count reasonable. Roof ideally one piece.

Corrosion touch-up: Detail local zinc-spray after welding.

Deliverables (PDF)

Assembly and exploded views.

Detail drawings of every part with dimensions, holes, weld symbols.

Bill of materials + fastener list.

Step-by-step line-art assembly guide.

Files: PDFs mandatory; DWG/STEP welcome.




700
ETH, DAI, USDT
+55
0 days (till Jul 11th, 2025)
